Indicator light ø 12mm 400V yellow connection male faston 6.3mm
Indicator light ø 12mm 400V green connection male faston 6.3mm
Cam switch 4 operating positions 2NO sequence 0-1-0-1 16A shaft
Level relay 230V voltage AC connection F6.3 type RL30/3ES/F/G
Safety thermostat switch-off temp. 150°C 3-pole 0,5A probe ø 3mm
Knob thermostat t.max. 100°C temperature range 0-100°C ø 73mm sh
Drain tap connection with union nut thread 1½"
Manometer ø 60mm pressure range 0 up to 1bar thread 1/8" marking
Safety valve triggering pressure 0,5bar thread 3/4"
Rotary selector mounting measurements ø22mm sequence 0-1 latchin
Level electrode 1/4" total length 350mm probe L 325mm insulated
Heating element 6000W 230V heating circuits 3 L 320mm W 40mm H 4
