Parts List
Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
DV40N Parts List
Flat gasket rubber ED ø 24mm ID ø 17mm thickness 2mm Qty 1 pcs
Flat gasket rubber ED ø 24mm ID ø 17mm thickness 2mm Qty 1 pcs
Countersunk screw thread M4 L 8mm SS DIN 965/ISO 7046 Qty 1 pcs
Countersunk screw thread M4 L 8mm SS DIN 965/ISO 7046 Qty 1 pcs
Pump inlet ø 45mm outlet ø 40mm type 3911K2533 180-253V 50Hz 1 p
Pump inlet ø 45mm outlet ø 40mm type 3911K2533 180-253V 50Hz 1 p
O-ring EPDM thickness 1,5mm ID ø 50mm Qty 1 pcs
O-ring EPDM thickness 1,5mm ID ø 50mm Qty 1 pcs
Hose clamp stainless steel ø 40-60mm width 9mm Qty 5 pcs DIN 301
Hose clamp stainless steel ø 40-60mm width 9mm Qty 5 pcs DIN 301
Bi-metal thermostat switch-off temp. 59°C 1NC 1-pole 16A connect
Bi-metal thermostat switch-off temp. 59°C 1NC 1-pole 16A connect
Equipment foot pipe type 40x40 thickness 1-1.2mm H 17-55mm plast
Equipment foot pipe type 40x40 thickness 1-1.2mm H 17-55mm plast
Mechanical shaft seal for shaft ø 11 mm slide ringext. ø 24 mm s
Mechanical shaft seal for shaft ø 11 mm slide ringext. ø 24 mm s
Heating element 2000W 230V heating circuits 1 L 250mm W 35mm H 2
Heating element 2000W 230V heating circuits 1 L 250mm W 35mm H 2
Displaying 1 to 20 (of 121 products)
