Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
Power terminal block 6-pole max. 40A max 450V connection ø6mm² /
Power contactor resistive load 22A 230VAC (AC3/400V) 9A/4kW main
Power terminal block 6-pole max. 40A max 450V connection ø6mm² /
Solenoid valve single angled 230VAC inlet 3/4" outlet 11,5mm DN1
Rinse arm L 215mm nozzles 4 mounting ø 18mm mounting pos. upper/
Extraction hose ED ø 8mm ID ø 5mm Qty supplied by meter
O-ring EPDM thickness 2,62mm ID ø 29,82mm Qty 10 pcs
Wash arm boss mounting pos. upper/lower ø 71mm ID ø 59mm L 135mm
O-ring EPDM thickness 5,34mm ID ø 56,52mm Qty 1 pcs
Heating element 6000W 230V mounting ø 57,5mm heating circuits 3
Thermometer mounting ø 52mm t.max. 120°C 0 up to +120°C probe ø
Indicator lamp green 250V connection male faston 6.3mm protectio
Bi-metal thermostat switch-off temp. 55°C 1-pole
Thermometer mounting ø 52mm t.max. 120°C 0 up to +120°C probe ø
Bi-metal thermostat switch-off temp. 55°C 1-pole
Safety thermostat switch-off temp. 140°C 3-pole 20A probe ø 6mm
Indicator lamp green 250V connection male faston 6.3mm protectio
