Parts List

Exploded diagrams, Schematics and other documents

Click on an image to enlarge the exploded view

HVG101P Ver:200803- Parts List

  • Version
Plain washer ø 30mm thickness 3mm hole ø 12,5mm for fan wheel co

Plain washer ø 30mm thickness 3mm hole ø 12,5mm for fan wheel co

Ref: Pg:3 Item:004

Plain washer ø 30mm thickness 3mm hole ø 12,5mm for fan wheel co

more info
Safety thermostat switch-off temp. 360°C 1-pole 20A probe ø 11mm

Safety thermostat switch-off temp. 360°C 1-pole 20A probe ø 11mm

Ref: Pg:3 Item:008

Safety thermostat switch-off temp. 360°C 1-pole 20A probe ø 11mm

more info
Female connector 4-pole

Female connector 4-pole

Ref: Pg:5 Item:007

Female connector 4-pole

more info
Hinge bearing without bolt mounting pos. upper left

Hinge bearing without bolt mounting pos. upper left

Ref: Pg:2 Item:013

Hinge bearing without bolt mounting pos. upper left

more info
Nut thread M12x1.25 H 5mm WS 17 brass Qty 1 pcs

Nut thread M12x1.25 H 5mm WS 17 brass Qty 1 pcs

Ref: Pg:2 Item:015

Nut thread M12x1.25 H 5mm WS 17 brass Qty 1 pcs

more info
Transformer primary 230VAC secondary 12VAC 40VA secondary 3,2A H

Transformer primary 230VAC secondary 12VAC 40VA secondary 3,2A H

Ref: Pg:3 Item:020

Transformer primary 230VAC secondary 12VAC 40VA secondary 3,2A H

more info
Hose ID ø 50mm ED ø 58mm L 50mm silicone Qty 1 for combi-steamer

Hose ID ø 50mm ED ø 58mm L 50mm silicone Qty 1 for combi-steamer

Ref: Pg:4 Item:021

Hose ID ø 50mm ED ø 58mm L 50mm silicone Qty 1 for combi-steamer

more info
Compression spring ø 12mm L 49mm wire gauge ø 1mm

Compression spring ø 12mm L 49mm wire gauge ø 1mm

Ref: Pg:6 Item:011

Compression spring ø 12mm L 49mm wire gauge ø 1mm

more info
Pressure control ø 45mm triggering pressure 0,5bar reset pressur

Pressure control ø 45mm triggering pressure 0,5bar reset pressur

Ref: Pg:4 Item:027

Pressure control ø 45mm triggering pressure 0,5bar reset pressur

more info
Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

Ref: Pg:6 Item:015

Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

more info
Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

Ref: Pg:4 Item:024

Push-in fitting John Guest T-piece pipe connection ø10mm - ø10mm

more info
Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

Ref: Pg:6 Item:019

Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

more info
Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

Ref: Pg:4 Item:023

Push-in fitting John Guest angled pipe connection ø10mm - ø10mm

more info
Fine fuse size ø5x20mm 2A fast-acting rated 250V Qty 10 pcs

Fine fuse size ø5x20mm 2A fast-acting rated 250V Qty 10 pcs

Ref: Pg:3 Item:022

Fine fuse size ø5x20mm 2A fast-acting rated 250V Qty 10 pcs

more info
Push-in fitting John Guest straight pipe connection ø10mm - ø10m

Push-in fitting John Guest straight pipe connection ø10mm - ø10m

Ref: Pg:6 Item:024

Push-in fitting John Guest straight pipe connection ø10mm - ø10m

more info
Counterflange for fan motor ED ø 60mm int. ø 1 34mm int. ø 2 25m

Counterflange for fan motor ED ø 60mm int. ø 1 34mm int. ø 2 25m

Ref: Pg:3 Item:002

Counterflange for fan motor ED ø 60mm int. ø 1 34mm int. ø 2 25m

more info
Shaft sealing ID ø 24mm ED ø 29mm thickness 3mm

Shaft sealing ID ø 24mm ED ø 29mm thickness 3mm

Ref: Pg:3 Item:033

Shaft sealing ID ø 24mm ED ø 29mm thickness 3mm

more info
Frame

Frame

Ref: Pg:2 Item:023

Frame

more info
Lamp glass L 105mm W 40mm thickness 4mm

Lamp glass L 105mm W 40mm thickness 4mm

Ref: Pg:2 Item:021

Lamp glass L 105mm W 40mm thickness 4mm

more info
Fan wheel D1 ø 350mm H1 114mm blades 12 D2 ø 19,5mm D3 ø 23mm H2

Fan wheel D1 ø 350mm H1 114mm blades 12 D2 ø 19,5mm D3 ø 23mm H2

Ref: Pg:3 Item:034

Fan wheel D1 ø 350mm H1 114mm blades 12 D2 ø 19,5mm D3 ø 23mm H2

more info
