Rail-mounted terminal Phönix Control type USLKG10 0.5-10mm² yell
Hexagonal nut thread M4 H 3,2mm WS 7 SS DIN/ISO DIN 934 / ISO 40
Lock washer ID ø 8,1mm ext. ø spring steel Qty 1 pcs for threa
Rail-mounted terminal type 6-10mm² W 8mm L 43mm max. 50A max 5
Probe clip for pipe ø 8,5mm for probe ø 6mm L 25mm Qty 10 pcs
Contactor resistive load 35A 230VAC main contacts 3NO
Flat-headed bolt thread M4 thread L 8mm head ø 8mm head thicknes
Cable gland mounting ø 20,6mm plastic Qty 1 pcs
Side bolts thread M5 L 16mm SS Qty 20 pcs intake slotted head ø
Magnetic switch L 28,5mm W 19mm 1NO 230V 0,5A P max. 10W connect
Plain washer ID ø 6,4mm ED ø 12mm thickness 1,6mm SS Qty 1 pcs D
Cylinder head bolt thread M5 thread L 16mm WS 4 intake internal
Bi-metal thermostat switch-off temp. 60°C 1NC 1-pole connection
