Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
O-ring EPDM thickness 2,62mm ID ø 20,63mm Qty 1 pcs
Blender stick FM3 L 400mm flange ø 47mm with blade
Bushing mounting pos. centre ø 25mm ID ø 22mm H 15mm FM3
Deep-groove ball bearing type 608-2Z shaft ø 8mm ED ø 22mm W 7mm
Motor for hand blender 230V 50Hz shaft ø 8mm mounting distance 5
Blender stick L 500mm flange ø 47mm with blade
Gear wheel double ø 45mm shaft ø 8mm shaft L 70mm with spindle F
Gear wheel single shaft ø 8mm shaft L 70mm with spindle FM3
Housing right green MX40 / MX42S L 330mm ø 120mm
Blender attachment mounting pos. lower ø 95mm ID ø 25mm H 84mm F
