R50 Ver:198505- Parts List
Hose connector brass straight thread M8 hose ø 6mm Qty 1 pcs
Hose connector brass straight thread M8 hose ø 6mm Qty 1 pcs
Snap lock L 70mm W 22mm H 56mm mounting distance 50mm
Snap lock L 70mm W 22mm H 56mm mounting distance 50mm
Interference suppression filter type 10S7E-G1474253105-Q 115/250
Interference suppression filter type 10S7E-G1474253105-Q 115/250
Rotary switch 2 0-1 sets of contacts 2 type CA0120002 380V 12A s
Rotary switch 2 0-1 sets of contacts 2 type CA0120002 380V 12A s
Equipment foot thread M10 thread L 40mm H 14mm ø 60mm
Equipment foot thread M10 thread L 40mm H 14mm ø 60mm
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
Solenoid valve single angled 230VAC inlet 3/4" outlet 11,5mm DN1
Solenoid valve single angled 230VAC inlet 3/4" outlet 11,5mm DN1
Flex hose SS braid straight-straight DN12 connections 3/4" L 200
Flex hose SS braid straight-straight DN12 connections 3/4" L 200
Indicator light ø 10mm yellow 230V connection male faston 6.3mm
Indicator light ø 10mm yellow 230V connection male faston 6.3mm
Flat gasket rubber ED ø 45mm ID ø 33mm thickness 3mm Qty 1 pcs
Flat gasket rubber ED ø 45mm ID ø 33mm thickness 3mm Qty 1 pcs
Solenoid coil ELBI 230VAC 50/60Hz pressure range 0 up to 10bar
Solenoid coil ELBI 230VAC 50/60Hz pressure range 0 up to 10bar
O-ring EPDM thickness 5,34mm ID ø 56,52mm Qty 1 pcs
O-ring EPDM thickness 5,34mm ID ø 56,52mm Qty 1 pcs
Hose clamp ø 16-27mm width 9mm Qty 10 pcs DIN 3017
Hose clamp ø 16-27mm width 9mm Qty 10 pcs DIN 3017
