Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
Knob without symbol ø 72mm BERTOS shaft ø 8x6.5mm shaft flat low
Ignition cable cable length 600mm connection ø2.4mm / lug M4
Piezoelectric igniter body plastic blowing mounting ø 18mm conne
Gas tap PEL type 21S gas inlet M16x1.5 (tube ø 10mm)
Thermocouple SIT M9x1 L 600mm plug connection ø6.0(6.5)mm
Nozzle holder nozzle mounting M10x1 tube ø 10mm gas inlet M16x1.
Pilot burner nozzle SIT natural gas code 41 Qty 1 pcs
Pilot burner nozzle SIT LPG code 25 Qty 1 pcs
Gas injector thread M10x1 WS 11 bore ø 2,05mm
Gas injector thread M10x1 WS 11 bore ø 1,3mm code 130
