ECO STAR 530F Parts List
Mechanical shaft seal for shaft ø 11 mm slide ringext. ø 24 mm s
Mechanical shaft seal for shaft ø 11 mm slide ringext. ø 24 mm s
Hose ID 6mm ED 12mm silicone Qty supplied by meter
Hose ID 6mm ED 12mm silicone Qty supplied by meter
Pump cover bottom part for FIR 3978/M 0.55 KW
Pump cover bottom part for FIR 3978/M 0.55 KW
Hose clamp ø 10-16mm width 9mm Qty 10 pcs DIN 3017
Hose clamp ø 10-16mm width 9mm Qty 10 pcs DIN 3017
O-ring EPDM thickness 1,5mm ID ø 50mm Qty 1 pcs
O-ring EPDM thickness 1,5mm ID ø 50mm Qty 1 pcs
Hose clamp ø 32-50mm width 9mm Qty 5 pcs DIN 3017
Hose clamp ø 32-50mm width 9mm Qty 5 pcs DIN 3017
Wash and rinse arm wash arm L 495mm rinse arm L 415mm w. jets 10
Wash and rinse arm wash arm L 495mm rinse arm L 415mm w. jets 10
Heating element 3000W 230V heating circuits 3 mounting ø 47,5mm
Heating element 3000W 230V heating circuits 3 mounting ø 47,5mm
Bi-metal safety thermostat switch-off temp. 110C 1NC 1-pole 16A
Bi-metal safety thermostat switch-off temp. 110C 1NC 1-pole 16A
Heating element 4500W 230V heating circuits 3 mounting ø 47,5mm
Heating element 4500W 230V heating circuits 3 mounting ø 47,5mm
Door hinge door bearing, right mounting pos. right
Door hinge door bearing, right mounting pos. right
Door hinge door bearing, left mounting pos. left
Door hinge door bearing, left mounting pos. left
Displaying 41 to 60 (of 93 products)
