DV80 AB 1992 Parts List
Ribbon cable 10-pole L 800mm plug type FC-10P raster size 2,54mm
Ribbon cable 10-pole L 800mm plug type FC-10P raster size 2,54mm
Rinse pipe mounting pos. upper left-hand thread
Rinse pipe mounting pos. upper left-hand thread
One ear clamp ø 16.6-19.8mm width 7mm strip thickness 0,6mm Qty
One ear clamp ø 16.6-19.8mm width 7mm strip thickness 0,6mm Qty
Heating element 3000W 230V heating circuits 3 mounting ø 47,5mm
Heating element 3000W 230V heating circuits 3 mounting ø 47,5mm
Bi-metal safety thermostat switch-off temp. 105°C 1-pole connect
Bi-metal safety thermostat switch-off temp. 105°C 1-pole connect
Pump inlet ø 63mm outlet ø 47mm type 1295.2503 230/400V 50 Hz 3
Pump inlet ø 63mm outlet ø 47mm type 1295.2503 230/400V 50 Hz 3
Hose connector thread 3/8" for hose ID 13-13mm angled plastic Qt
Hose connector thread 3/8" for hose ID 13-13mm angled plastic Qt
Fine fuse size ø5x20mm 4A medium lag rated 250V Qty 10 pcs
Fine fuse size ø5x20mm 4A medium lag rated 250V Qty 10 pcs
