L23 Ver:1993 Parts List
Hexagonal nut thread M5 H 4mm WS 8 SS DIN/ISO DIN 934 / ISO 4032
Hexagonal nut thread M5 H 4mm WS 8 SS DIN/ISO DIN 934 / ISO 4032
Deep-groove ball bearing type 6002-2Z shaft ø 15mm ED ø 32mm W 9
Deep-groove ball bearing type 6002-2Z shaft ø 15mm ED ø 32mm W 9
Hexagonal screw thread M10 thread L 35mm SS WS 17 Qty 1 pcs DIN
Hexagonal screw thread M10 thread L 35mm SS WS 17 Qty 1 pcs DIN
Overload switch setting range 1.8-2.6A for contactors LC1K
Overload switch setting range 1.8-2.6A for contactors LC1K
Hose clamp ø 60-80mm width 9mm Qty 5 pcs DIN 3017
Hose clamp ø 60-80mm width 9mm Qty 5 pcs DIN 3017
Union nut dosing pump thread 1/2" ø 32mm H 15mm for dosing pum
Union nut dosing pump thread 1/2" ø 32mm H 15mm for dosing pum
Gasket with 4 screw holes ED ø 134mm ID ø 65mm thickness 2,5mm
Gasket with 4 screw holes ED ø 134mm ID ø 65mm thickness 2,5mm
Formed hose L 130mm dishwasher straight hose ext. ø 50mm
Formed hose L 130mm dishwasher straight hose ext. ø 50mm
Basket support for dishwasher L 580m W 510mm H 75mm
Basket support for dishwasher L 580m W 510mm H 75mm
O-ring EPDM thickness 3mm ID ø 59,2mm Qty 1 pcs
O-ring EPDM thickness 3mm ID ø 59,2mm Qty 1 pcs
Power contactor resistive load 25A 230VAC (AC3/400V) 9A/4kW main
Power contactor resistive load 25A 230VAC (AC3/400V) 9A/4kW main
Bush for wash arm mounting pos. upper H 52mm thread 1¼" D1 ø 54m
Bush for wash arm mounting pos. upper H 52mm thread 1¼" D1 ø 54m
