IM18C Ver:Vers1 Parts List
Connector single DIN/ISO 06 B-1 splitting 3/8" links 1 L 17,8mm
Connector single DIN/ISO 06 B-1 splitting 3/8" links 1 L 17,8mm
Chain DIN/ISO 05 B-1 splitting 8mm links 71 internal width 3mm r
Chain DIN/ISO 05 B-1 splitting 8mm links 71 internal width 3mm r
Roller chain DIN/ISO 06 B-1 splitting 3/8" / 9.525mm links 36
Roller chain DIN/ISO 06 B-1 splitting 3/8" / 9.525mm links 36
Drive flange ø 280mm ID ø 50mm thickness 3mm 12-18 C
Drive flange ø 280mm ID ø 50mm thickness 3mm 12-18 C
Mixer bowl for dough mixer ID ø 360mm H 210mm detachable 18 C
Mixer bowl for dough mixer ID ø 360mm H 210mm detachable 18 C
Microswitch with plunger mounting distance 25mm thread M12x1 thr
Microswitch with plunger mounting distance 25mm thread M12x1 thr
Momentary push switch mounting measurements ø22mm white 1NO I mo
Momentary push switch mounting measurements ø22mm white 1NO I mo
Retaining ring shaft 20mm thickness 13mm steel DIN 471
Retaining ring shaft 20mm thickness 13mm steel DIN 471
Mounting flange ø 340mm ID ø 113mm thickness 3mm 18 C
Mounting flange ø 340mm ID ø 113mm thickness 3mm 18 C
Bearing block for dough hook ø 115mm ID ø 42mm H 62mm edition un
Bearing block for dough hook ø 115mm ID ø 42mm H 62mm edition un
Drive shaft D1 ø 20mm ø 24mm L 458mm 12-18 C-F D2 ø 17mm edition
Drive shaft D1 ø 20mm ø 24mm L 458mm 12-18 C-F D2 ø 17mm edition
Deep-groove ball bearing type 6004-2RS shaft ø 20mm ED ø 42mm W
Deep-groove ball bearing type 6004-2RS shaft ø 20mm ED ø 42mm W
Rotary switch 2 1-2 sets of contacts 8 type T0-4-969I/E 400V 16A
Rotary switch 2 1-2 sets of contacts 8 type T0-4-969I/E 400V 16A
