Parts List
Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
Niagara-283A Ver:201109- Parts List
Pressure control hose ID ø 5mm ED ø 9mm L 5m operating p. 30bar
Pressure control hose ID ø 5mm ED ø 9mm L 5m operating p. 30bar
Air trap L 46mm W 35mm H 72mm thread 3/4" hose ø 5,5mm plastic
Air trap L 46mm W 35mm H 72mm thread 3/4" hose ø 5,5mm plastic
Pump inlet ø 12 outlet ø 12 type PPL46DX 230V 50Hz 0,33kW capaci
Pump inlet ø 12 outlet ø 12 type PPL46DX 230V 50Hz 0,33kW capaci
Solenoid valve single straight 230VAC inlet 34
Solenoid valve single straight 230VAC inlet 34
Backflow preventer connection 1/2" dishwasher hose ø 12mm
Backflow preventer connection 1/2" dishwasher hose ø 12mm
Power terminal block 6-pole max. 40A max 450V connection ø6mm² /
Power terminal block 6-pole max. 40A max 450V connection ø6mm² /
Nut thread M3 H 3,5mm plastic Qty 1 pcs for PCB
Nut thread M3 H 3,5mm plastic Qty 1 pcs for PCB
O-ring EPDM thickness 2,62mm ID ø 23,81mm Qty 10 pcs
O-ring EPDM thickness 2,62mm ID ø 23,81mm Qty 10 pcs
O-ring EPDM thickness 5,34mm ID ø 47mm Qty 1 pcs
O-ring EPDM thickness 5,34mm ID ø 47mm Qty 1 pcs
Spacer for PCB L 18mm W 6mm D1 ø 6mm D2 ø 3mm
Spacer for PCB L 18mm W 6mm D1 ø 6mm D2 ø 3mm
Pressure hose ID ø 13mm ED ø 21mm L 5m operating p. 10bar burst
Pressure hose ID ø 13mm ED ø 21mm L 5m operating p. 10bar burst
Fine fuse size ø5x20mm 4A fast-acting rated 250V Qty 10 pcs
Fine fuse size ø5x20mm 4A fast-acting rated 250V Qty 10 pcs
Displaying 21 to 40 (of 113 products)
