Pump inlet ø 60mm outlet ø 48mm type A.4.5/2.6 220-240/380-415V
Timer CDC 4904F engines 1 chambers 4 operation time 6min 230V
Hexagonal screw thread M8 thread L 20mm SS WS 13 Qty 1 pcs DIN 9
Formed hose end piece A ext. ø 43mm end piece A int. ø 35mm AD2
Mechanical shaft seal for shaft ø 12mm slide ringext. ø 24mm sli
Timer CDC 4904F engines 1 chambers 4 operation time 6min 230V 60
Wash arm support mounting pos. lower thread 1½" ø 41,5mm H 168mm
