76U DS40-Olis Ver:200511-Rev.01 Parts List
Heating element 4000W 230V mounting ø 38,5mm heating circuits 3
Heating element 4000W 230V mounting ø 38,5mm heating circuits 3
Wash arm mounting pos. right L 132mm nozzles 3 mounting ø 22mm
Wash arm mounting pos. right L 132mm nozzles 3 mounting ø 22mm
Wash arm bearing mounting pos. upper/lower 3 holes hole ø 3mm se
Wash arm bearing mounting pos. upper/lower 3 holes hole ø 3mm se
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
O-ring EPDM thickness 3,53mm ID ø 34,52mm Qty 1 pcs
Drain fitting thread 1" ED ø 29,5mm ID ø 25mm
Drain fitting thread 1" ED ø 29,5mm ID ø 25mm
Wash arm L 395mm nozzles 6 mounting pos. upper/lower
Wash arm L 395mm nozzles 6 mounting pos. upper/lower
Wash and rinse arm wash arm L 400mm rinse arm L 400mm w. jets 5
Wash and rinse arm wash arm L 400mm rinse arm L 400mm w. jets 5
Inlet valve overall height 79mm ø 94mm thread 1" ET
Inlet valve overall height 79mm ø 94mm thread 1" ET
Rinse arm L 375mm nozzles 5 mounting pos. lower
Rinse arm L 375mm nozzles 5 mounting pos. lower
Wash arm support mounting pos. lower open contact for dosing pum
Wash arm support mounting pos. lower open contact for dosing pum
Displaying 141 to 160 (of 216 products)
