Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
Fuse holder suitable fuse D02 1-pole-pole 63A rated 400V
Safety thermostat switch-off temp. 340°C 1-pole 16A probe ø 3mm
PCB terminal block 12-pole raster size 3,5mm flat
Fine fuse size ø6.3x32mm 6,3A fast-acting rated 500V Qty 10 pcs
Fine fuse size ø6.3x32mm 6,3A fast-acting rated 500V Qty 10 pcs
Temperature probe thermocouple K (NiCr-Ni) cable silicone probe
Temperature probe thermocouple K (NiCr-Ni) cable silicone probe
Power contactor resistive load 60A 230VAC (AC3/400V) 32A/16kW ma
Power contactor resistive load 60A 230VAC (AC3/400V) 32A/16kW ma
Keypad PCB combi-steamer OSx xx.xx L 322mm W 117mm V5.19 buttons
Solenoid valve triple angled 230VAC inlet 3/4" outlet 14,5mm DN1
Rail-mounted terminal WIELAND type 9700A/16 S35 2.5-35mm² top-ha
Rail-mounted terminal WIELAND type 9700A/16 S35 2.5-35mm² top-ha
Rail-mounted terminal WIELAND type 9700A/16 S35 2.5-35mm² top-ha
