LF280-lav-line Parts List
O-ring EPDM thickness 5,34mm ID ø 81,92mm Qty 1 pcs
O-ring EPDM thickness 5,34mm ID ø 81,92mm Qty 1 pcs
Thermostat t.max. 90°C temperature range 30-90°C 1-pole 1CO 16A
Thermostat t.max. 90°C temperature range 30-90°C 1-pole 1CO 16A
Heating element 3000W 230V mounting ø 57,5mm heating circuits 1
Heating element 3000W 230V mounting ø 57,5mm heating circuits 1
Bush H 13,5mm D1 ø 20mm D2 ø 16mm D3 ø 12mm for wash arm
Bush H 13,5mm D1 ø 20mm D2 ø 16mm D3 ø 12mm for wash arm
O-ring EPDM thickness 3,53mm ID ø 183,75mm Qty 1 pcs
O-ring EPDM thickness 3,53mm ID ø 183,75mm Qty 1 pcs
Heating element 2400W 230V heating circuits 1 flange 70x18mm L 3
Heating element 2400W 230V heating circuits 1 flange 70x18mm L 3
O-ring EPDM thickness 2,62mm ID ø 13,1mm Qty 1 pcs
O-ring EPDM thickness 2,62mm ID ø 13,1mm Qty 1 pcs
Wash arm support mounting pos. upper with rinse arm shaft
Wash arm support mounting pos. upper with rinse arm shaft
Opposite support mounting pos. lower for wash arm
Opposite support mounting pos. lower for wash arm
Thermowell thread 1/2" L 44mm SS single ø 10mm
Thermowell thread 1/2" L 44mm SS single ø 10mm
Pull handle L 170mm H 37mm mounting distance 150mm thread M5 W 3
Pull handle L 170mm H 37mm mounting distance 150mm thread M5 W 3
Side bolts thread M6 L 25mm SS Qty 1 pcs intake slotted head ø 1
Side bolts thread M6 L 25mm SS Qty 1 pcs intake slotted head ø 1
