L45 Ver:20010101-20060521 Parts List
Handle rail L 555mm W 26mm H 35mm grey hole distance 110mm
Handle rail L 555mm W 26mm H 35mm grey hole distance 110mm
Thermostat t.max. 90°C temperature range 30-90°C 1-pole 1CO 16A
Thermostat t.max. 90°C temperature range 30-90°C 1-pole 1CO 16A
Thermostat t.max. 60°C temperature range 30-60°C 1-pole 1CO 16A
Thermostat t.max. 60°C temperature range 30-60°C 1-pole 1CO 16A
Formed hose warewashing L-shape hose int. ø 44mm
Formed hose warewashing L-shape hose int. ø 44mm
Cam switch 3 operating positions operation switch sequence 0-1-2
Cam switch 3 operating positions operation switch sequence 0-1-2
Tension spring ø 11mm total length 210mm wire gauge ø 1,9mm
Tension spring ø 11mm total length 210mm wire gauge ø 1,9mm
O-ring EPDM thickness 3,53mm ID ø 23,4mm Qty 10 pcs
O-ring EPDM thickness 3,53mm ID ø 23,4mm Qty 10 pcs
O-ring EPDM thickness 3,53mm ID ø 23,4mm Qty 10 pcs
O-ring EPDM thickness 3,53mm ID ø 23,4mm Qty 10 pcs
Pump inlet ø 45mm outlet ø 38mm type ZF320VSX 230V 50Hz 1 phase
Pump inlet ø 45mm outlet ø 38mm type ZF320VSX 230V 50Hz 1 phase
Timer FIBER P25 engines 2 chambers 5 operation time 108s / 6min
Timer FIBER P25 engines 2 chambers 5 operation time 108s / 6min
Formed hose hose ext. ø 48mm hose int. ø 39mm L 235mm Qty 1 S-sh
Formed hose hose ext. ø 48mm hose int. ø 39mm L 235mm Qty 1 S-sh
